Difference Between Power Transformer and Distribution Transformer

What is a Distribution Transformer?

A distribution transformer is an essential electrical device that delivers power from the main electrical grid to end users, such as homes, commercial buildings, and businesses. These transformers are commonly mounted on utility poles in residential neighborhoods, attached to building exteriors, or installed underground in areas where overhead lines aren't feasible.

Often referred to as step-down transformers, they serve the crucial function of reducing high transmission voltages to safer, lower levels suitable for household appliances and electronic devices. Inside the transformer casing, large copper wire coils are wrapped around an iron core. As electricity flows through these coils, the magnetic field in the core enables energy transfer between windings, effectively lowering the voltage without physical connection.

Unlike distribution feeder lines, which serve multiple buildings or facilities, a distribution transformer typically connects to a single building or a small group of structures. While it shares structural similarities with an autotransformer, a distribution transformer is specifically designed to supply current independently to both the primary and secondary circuits.

Types of Distribution Transformers

Distribution transformers play a key role in voltage regulation and load distribution across power systems. They come in various sizes and ratings, and are typically classified into four main types based on their configuration and application:

1. Single-Phase Distribution Transformer

Single-phase transformers are designed for use in single-phase power systems, commonly found in residential applications. The primary winding is connected to a three-phase supply using three separate terminals, while the secondary side consists of a single winding per phase connected to the load. The secondary voltage is determined by the sum of the phase voltages, each modified by its corresponding turns ratio. These transformers are ideal for smaller loads where a full three-phase system isn’t necessary.

2. Three-Phase Distribution Transformer

Three-phase transformers are used in larger commercial or industrial power systems. They consist of three primary and three secondary windings, typically connected in a delta or wye configuration. The secondary windings generate voltages that are 120 degrees out of phase with one another, providing a balanced power supply. These transformers can deliver higher loads efficiently and are suited for powering heavy-duty equipment and large facilities.

3. Pad-Mounted Transformer

Pad-mounted transformers are installed on ground-level concrete pads and are enclosed in locked metal cabinets for safety. These units are often used in suburban neighborhoods, commercial complexes, or areas without overhead lines. Their design allows for underground cable connections, minimizing visual clutter and exposure to weather elements. They are commonly deployed where aesthetics, safety, or space limitations make overhead installations impractical.

4. Pole-Mounted Transformer

Pole-mounted transformers are installed on utility poles above ground and are commonly used in rural and residential areas. Their elevated position makes them easy to service and helps prevent damage from flooding or tampering. These units may also serve specialized roles, such as supporting capacitor banks or recloser systems. Additional features can include bushings, lightning arrestors, and grounding connections for enhanced safety and reliability.

Difference Between Power Transformer and Distribution Transformer

Power Transformers and Distribution Transformers are used for high voltage, low current applications. However, there are some differences between the two:

Transformer Size / Insulation Level

Power transformers have a higher insulation level than distribution transformers. Power transformers have a voltage rating of more than 1 kV and can withstand short circuit currents up to a few hundred amperes. In comparison, distribution transformers have a voltage rating of less than 1 kV and can withstand short circuit currents up to tens of amperes.

Iron and Copper Losses

Power transformers experience energy loss as heat, primarily due to eddy current losses in their steel laminations and hysteresis losses in the core material. Distribution transformers, which do not contain iron parts, have significantly lower iron losses compared to power transformers. However, they still experience energy losses due to hysteresis in the core material, though these losses are much smaller. This is because distribution transformers are smaller in size, resulting in less heat generation, especially when handling lower currents.

Maximum Efficiency

Power transformers are typically less efficient than distribution transformers due to their larger size and higher current load. A typical distribution transformer may have an efficiency rating of 90% or higher, while standard power transformers usually have an efficiency rating of around 80%. That said, certain types of power transformers can achieve efficiencies ranging from 97% to 99%.

Conclusion

Power transformers are designed to adjust voltage levels for transmission, while distribution transformers are specifically intended to provide lower voltages to consumers. There is a wide range of distribution transformers available, each offering its own set of advantages and limitations. If you're in search of a high-quality power transformer tailored to your needs, we highly recommend considering products from CHINT. With years of industry experience, we specialize in designing and manufacturing premium transformers that are built to exceed your expectations.
